AC 2 Sources + 9 Positions

• Double pole AC main circuit breakers with installed lockout slide




• Prevents connecting both AC sources simultaneously




• Maximum panel amperage - 50 Amperes




• Red reverse polarity indicating LED




• All hot, neutral and safety ground buses installed, fully pre-wired




• All circuit label positions are backlit on standard panels - No kit required




• "ON" indicating LEDs installed in all circuit positions




• MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance




• Two-part polyurethane slate gray finish




• Heavy 1/8" aluminum 5052 alloy




• Industry standard height and width




• Countersunk mounting holes throughout




• Detailed installation instructions and cutout template included
