UP28R Rear Mount Helm 1.7 cu. 3/4" Tapered Stainless Steel Shaft

Features:

• Available in four different displacement sizes


• Compact design


• Ball bearing piston race


• Built-in lock valve for positive rudder lock


• Integral relief valve for over-pressure protection


• 3/4 tapered stainless steel shaft


• Easily accessible lock valve and shaft seal for replacement


• Cast iron cylinder rotor for greater durability and longer life


• 1/4" NPT fitting for 3/8" tube


• Includes 90 adjustable fittings for 3/8 tube and white bezel


• UP45R pump is ideal for double cylinder outboard applications


• UP45 pump is available also for inboard application


• X68 (optional) - 40894Z Chrome bezel


• KITF (optional) - 39664Y Remote fill adapter

Specifications:

• Mounting: Retro-cruscotto


• Displacement/Revolution: 28 cc-1.7 cu in


• # of Pistons: 5


• Relief Valve Setting: 70 Bar - 1000 PSI


• Maximum Wheel Diameter: 710mm - 28"


• Weight: 5kg - 11 lbs.
